BO MẠCH CHỦ | MAINBOARD VSP X99 - Q8M PRO
  • Mã sản phẩm: 20241102-1363
  • Còn hàng
  • Mã sản phẩm: X99 - Q8M PRO
  • Form Factor: E-ATX
  • Dimension: 305mm X 330mm
  • Memory Type: 8 X DDR4 QUAD/ OCTAL DIMM, 2133/2400MHZ (Max), Maximum support of 256G (32G X8)
  • Expansion Interface: 3 X M.2 Slot
    (CN1&CN2: PCIE X 4 3.0 From CPU1 1);
    (CN3: PCIE X4 3.0/ SATA 3.0 From PCH)
  • CPU Socket: DUAL-CHANNEL INTEL XEON E5 LGA2011-V3
    (TWO CPU MODELS NEED TO BE THE SAME)
  • SATA: 10 X SATA 3.0
  • Network Header: 2 X RJ45  0
  • Network Card Chip: RTL8125BG/2.5G
  • Power Input: 24 PIN + 2 X 8PIN ATX POWER SOCKET
Tổng quan sản phẩm
Chi tiết kỹ thuật
  • Mã sản phẩm
    X99 - Q8M PRO
  • Form Factor
    E-ATX
  • Dimension
    305mm X 330mm
  • PCIE
    PCIE 5/6 Full-Length Slot: PCIE x 16 3.0 (From CPU 2)
    PCIE4 Full-Length Slot: PCIE X 8 3.0 (From CPU 2)
    PCIE3 Full-Length Slot: PCIE X 16 3.0 (From CPU 1)
    PCIE1/2 Full-Length Slot: PCIE X 8 3.0 (From CPU 1)
  • Memory Type
    8 X DDR4 QUAD/ OCTAL DIMM, 2133/2400MHZ (Max), Maximum support of 256G (32G X8)
  • Expansion Interface
    3 X M.2 Slot:
    (CN1&CN2: PCIE X 4 3.0 From CPU1 1);
    (CN3: PCIE X4 3.0/ SATA 3.0 From PCH)
  • CPU Socket
    DUAL-CHANNEL INTEL XEON E5 LGA2011-V3
    (TWO CPU MODELS NEED TO BE THE SAME)
  • SATA
    10 X SATA 3.0
  • Network Header
    2 X RJ45
  • USB Ports
    4 X USB 2.0, 4 X USB 3.0
    BUILT-IN PINS: 2 SETS OF USB2.0 PINS (4 USB 2.0 PORTS CAN BE EXPANDED); 1 SET OF USB 3.0 PINS (2 USB3.0 PORTS CAN BE EXPANDED)
  • Network Card Chip
    RTL8125BG/2.5G
  • Power Input
    24 PIN + 2 X 8PIN ATX POWER SOCKET
